DOBOT MG400 Robotic Arm
by Dobot
Contact for Price
DOBOT MG400 is a lightweight, space-saving desktop robotic arm suitable for diversified manufacturing needs. Discover more features of MG400 cobot in small space applications.
Specifications
| Number of Axes | 4 |
| Payload | 500 g (Max. 750 g) |
| Working Radius | 440 mm |
| Repeatability | ±0.05 mm |
| Range of Motion | ±160° |
| J2 | 300° /s |
| J3 | 300° /s |
| J4 | 300° /s |
| Maximum Joint Speed | 300° /s |
| Power | 100~240V AC, 50/60 Hz |
| Rated Voltage | 48V |
| Power Consumption | 150W |
| Communication Interface | TCP/IP, Modbus TCP |
| Installation | Desktop |
| Weight | 8 kg |
| Base Size | 190 mm × 190 mm |
| Environment | 0° ～ 40° C |
Key Features
Desktop Grade Compact
Industrial Grade Performance
Simplicity for Usability
Wide Array of Programming Options
Loading and Unloading
Assembly
Gluing
Quality Inspection
